বোরে রোটারি হ্যামার ড্রিল মেশিন
Operating controls
1• Dust cap
2• Locking sleeve
3• Cooling vents
4• Drilling depth stop5 Auxiliary handle
6• Release button
7• Mode selector knob
8• Reversing switch (2 -20 SER, 2-24SER)9 ON/OFF switch
10• Speed control (2-20 SER, 2.24SER)
11• ON/OFF switch locking button
Tools Specification
• Hammer drill Machine
• Power Out: 6500w
• No-Load RPM: 0-850/min
• Impact Rate: 0...3900/mini 0... 4850/min
• Impact Energy Per Stroke 1.5J- 2.15 J
• Tools Holder: SDS-Plus
• Chisel adjustment: 36 position
Driving Performance (Max.)
Stone: 20mm, 24mm
Granite: 20mm, 16mm
Wood: 30mm
Steel: 13mm
Weight (Without accessories) approx.2.3Kg -2.4Kg
